SOLAR KNIGHT®: SOLAR POWERED LIQUID LEVEL ALARM CP1003

PRODUCTS / LIQUID LEVEL ALARMS
LITERATURE

The Solar Knight® liquid level alarm will notify maintenance personnel in the event of a high liquid condition. The system is complete with visual indicators and dry contacts to connect to a dialer (optional) or building automation system.

REQUEST A QUOTE

Features

  • Solar cell provides 24/7 continuous power to high liquid alarm panel
  • UL Listed for the United States and Canada
  • Includes Narrow Angle Float Switch with 20′ cord
  • Indoor/Outdoor NEMA 4X rated enclosure: Heavy duty polycarbonate with stainless steel lockable latches
  • Includes 10 Watt multi-crystalline solar panel, 12V, 9.0 Amp Hr. sealed rechargeable battery, and solar charger
  • Quick installation and low maintenance
  • High liquid alarm with test and silence features, red beacon alarm light, high 85 decibel audible alarm.
  • Dry contact for high liquid condition
  • Solar panel mounting hardware
  • Easily accessible terminal block

Add Pump Portal® remote pump monitoring to this control panel!

Applications

  • Sewage and wastewater
  • Remote or rural containment
  • Flood zones
  • Industrial sumps
  • Holding tanks
  • Residential tanks
  • Lift stations
  • Leach line

Custom Options

  • 28 = Power On Dry Contact
  • 3R = Painted Steel Enclosure
  • AF = Alarm Flasher
  • C = Additional cord length greater than 20′*
  • PX = Pump Portal® Wireless Remote System Monitoring
  • S3 = No Sensors Included
  • SS4 = Upgraded Enclosure (304 Stainless Steel)
  • SS6 = Upgraded Enclosure (316 Stainless Steel)

*Additional cord length greater than 20′: Specify after C. Example: (CP1003-C50) Indicates 50′ cable length for narrow angle float.
